Screw oil press machine

Author:小编Time:2021-11-25Views:

Brief introduction of screw palm oil extraction press machine:

1. This automatic screw oil press machine is the quite advanced one among the processing machinery of oil plants.
2. It can be applied to the coconuts, olive, sunflower, soybean,cotton seeds , tee seeds rice bran, flaxseeds, sesame, peanuts, rape, cocoa etc.

3. It is labour saving and cost saving, only need 1 person can operate the oil press machine.

4. It includes screw oil press, eletrical element for heating chamber and the vacuume filter can be for clearing the crude oil.

5. The oil left in cake is less than 6% . And cake thickness can be adjusted once the machine stop running.


Main technicial parameters of screw oil press machine:

ModelD-1685D-1688ZL-120ZL-150
Diameter of squeezing boltφ80mmφ100mmφ120mmφ148mm
Speed of squeezing bolt60r/min40r/min36r/min36r/min
Diameter of internal circle of pressing chestφ82mmφ102mmφ122mmφ150mm
Configuration powerMain engineY112M-6 5.5KWY132M-6 7.5KWY160M-6 11KWY30KW-4
Heater3KW3.5KW4KW5KW
Handing capacity80-160kg/hr150-260kg/hr260-400kg/hr400-500kg/hr
Weight of complete machine780kg1100kg1500kg1800kg
External dimensions(mm)1700*1300*16002000*1400*17502050*1550*18002200*1460*1750

Screw oil press machine(图1)


Screw oil press machine(图2)


Screw oil press machine(图3)

screw type oil pess machine.jpg
