Brief introduction of the peanut butter machine:
1. This peanut butter machine is maily used to crush material into paste. jam in food, medician,chemical area.
2. The raw material could be peanut, sesame , Cocoa, almond etc.
3. The final paste is more fine and have big capacity.
4. The standard type machine material : All the parts connecting with raw material are Stainless Steel , Stator and Rotor parts are SS 420. Other parts are Carbon steel. The machine material can be customized to 304 stainless steel or 316 Stainless Steel.
Model | JMS-50 | JMS-80 | JMS-110 | JMS-130 | JMS-160 | JMS-180 | JMS-240 | JMS-300 | |
Output size/μm | 50-100 | 50-100 | 100-200 | 100-200 | 100-200 | 100-200 | 100-200 | 60-200 | |
output( kg/h ) | 8-10 | 70-100 | 300 | 400-600 | 600-800 | 800 | 1500-2000 | 3000-4000 | |
Motor | Power/KW | 1.5/1.1 | 4 | 7.5 | 11 | 15 | 18.5 | 45 | 75 |
Voltage/V | 220/380 | 220/380 | 380 | 380 | 380 | 380 | 380 | 380 | |
Rotate speed r/min | 2820 | 2890 | 2900 | 2930 | 2930 | 2930 | 2970 | 2970 | |
Dia of rotor/mm | 50 | 80 | 110 | 130 | 130 | 160 | 240 | 300 | |
Dimension(L*W*H) MM | 530*260*580 | 640*410*900 | 700*430*980 | 830*440*1100 | 830*440*1100 | 1000*460*1050 | 1320*500*1280 | 1440*630*1420 | |
Weight(Kg) | 50 | 150 | 175 | 285 | 300 | 340 | 920 | 1300 |
